Product Features
1. Modified sine wave output waveform;
2. High transform efficiency, fast start, small no load current;
3. Soft start function; reduce load’s starting risk;
4. Perfect protection, with low voltage, over voltage, over load, over temperature, short circuit, input reverse connection protections and etc.;
5. Intelligent temperature control fan, when loads over 30%, it will start. Saving energy, safe and high efficiency;
6. Imported electronic Components; built-in fuse, safe and reliable;
7. DC input voltage 12V, 24V, 48V, AC output voltage 100V, 110V, 120V, 220V, 230V, 240V and kinds of socket types;
8. CE-EMC/LVD, RoHS
| Model | M3000-12-110 | M3000-24-110 | M3000-48-110 | M3000-12-220 | M3000-24-220 | M3000-48-220 | ||
| Continuous Output Power | 3000W | 3000W | 3000W | 3000W | 3000W | 3000W | ||
| Peak Power | 6000W (<5ms) | |||||||
| DC Input Voltage | 12V | 24V | 48V | 12V | 24V | 48V | ||
| AC Output Voltage | 110VAC±10% | 220VAC±5% | ||||||
| No-load Current | ＜2.2A(DC13V) | ＜1.5A(DC26V) | ＜1.1A(DC52V) | ＜2.2A(DC13V) | ＜1.5A(DC26V) | ＜1.1A(DC52V) | ||
| AC Output Frequency | 50HZ±1%/60HZ±1% | |||||||
| AC Output Waveform | Modified Sine Wave | |||||||
| Waveform Distortion | THD<3%(Linear load) | |||||||
| Efficiency | ＞86%(DC13V) | ＞88%(DC26V) | ＞90%(DC52V) | ＞86%(DC13V) | ＞88%(DC26V) | ＞90%(DC52V) | ||
| DC Input Voltage Range | 11V～15V | 22V～30V | 44V～60V | 11V～15V | 22V～30V | 44V～60V | ||
| Low Voltage Alarm | 10.5±0.3V | 21±0.6V | 41.8±1.2V | 10.5±0.3V | 21±0.6V | 41.8±1.2V | ||
| Low Voltage Shutdown | 9.5±0.2V | 19±0.3V | 38±0.4V | 9.5±0.2V | 19±0.3V | 38±0.4V | ||
| Over Voltage Protection | 16±0.5V | 31±1V | 65±2V | 16±0.5V | 31±1V | 65±2V | ||
| Low Voltage Recovery | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V | ||
| Over Voltage Recovery | 15.7±0.3V | 31.8±0.4V | 63±1V | 15.7±0.3V | 31.8±0.4V | 63±1V | ||
| Over Load Protection | 120%～125% | |||||||
| Protective Function | Low voltage: LED red light, Buzzer alarm, automatic recovery | |||||||
| Over voltage: LED red light, automatic recovery | ||||||||
| Over load: LED red light, automatic shut down, need restart | ||||||||
| Over temperature: LED red light, Buzzer alarm, automatic recovery | ||||||||
| Short circuit (within 2s): automatic recovery | ||||||||
| Input reverse connection: fuse burn-out | ||||||||
| Working Temp. | -10°C-40°C | |||||||
| Storage Temp. | -30°C-70°C | |||||||
| Humidity | 20%～90%RH Non-condensing | |||||||
| Working Altitude | ≦3000m | |||||||
| Machine Size | 475*199*73mm | |||||||
| Net Weight | 5.66±0.05kg | |||||||
| Packing Size | 560*300*250mm | |||||||
| Gross Weight | 7.16±0.05kg | |||||||
| Socket types |   |
|||||||
